DaHua IP Intercom 10″ TFT Capacitive touch screen 1024 × 600 – DHI-VTH5441G
DHI-VTH5441G
Digital VTH (SIP 2.0)
> 10″ TFT Capacitive touch screen, 1024 × 600
> IPC surveillance
> Alarm integration
> Embedded 8GB SD card
> Record & Snapshot
> IPC surveillance
> Alarm integration
> Embedded 8GB SD card
> Record & Snapshot
Datasheet
User Manual
Description
System Parameter | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating System | Embedded LINUX operating system | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network Protocol | IPv4, FTP, RTSP, RTP, TCP, UDP, SIP | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Keyboard Type | Touch keyboard (0–9, *, #) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Basic Parameter | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Screen Type | Capactive screen | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Display | 10-inch TFT LCD | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Resolution | 1024 (H) × 600 (V) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Video Compression | H.264 | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Compression | G.711a, G.711Mu, G.711u, PCM | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Input | 1 channel all-direction microphone | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Output | 1 channel | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Mode | Support dual-way bidirectional talk | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Audio Enhancement | Support echo suppression/DNR | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Function Parameter | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Communication Mode | Full digital | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Leave Videos or Text Messages | Support | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
DND Mode | Support | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Sub-station Quantity | 9 |
Edge Storage | Embedded 8 GB | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Port | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Input | 6 channels | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Output | 1 channel | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Doorbell | Supported by every channel | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Network | 1 RJ-45, 10 M/100 Mbps self-adaptive | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Alarm Parameter | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
SOS Alarm | Support | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
General Parameter | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Casing | PC ABS | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Appearance Color | Black | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Supply | Standard PoE DC 12V 1A |
||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power | Optional | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Installation | Surface | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Certifications | CE/FCC | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Dimensions | 260 mm × 170 mm × 28 mm (10.24″ × 6.69″ × 1.10″) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Temperature | -10°C to 55°C ( 14°F to 131°F ) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Operating Humidity | 10%RH–90%RH (No condensation) | ||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
Power Consumption | ≤7W (Work) |
Datasheet
User Manual
Additional information
Weight | 1 kg |
---|---|
Dimensions | 26 × 17 × 3 cm |
